Advantech Wireless Technologies delivers intelligent broadband communications solutions that achieve excellence and maximize performance with uncompromising quality. Ultimately, we help people stay connected and informed by designing and manufacturing advanced terrestrial and satellite communication… подробнее
Overview
The Advantech’s Low Noise Amplifier (LNA) ALNA-X is a low noise, highly dynamic range amplifier suitable for use in satellite earth station receiver applications where ultra low noise and high reliability are critical. Advantech also provides LNAs in C, S Ku and Ka bands. The X-band LNA is available with Noise Temperature ranging from 60 K to 70 K. With weatherproof packaging, the LNA can meet the demands of the installations in severe environmental conditions. The 1:1 and 1:2 redundant system configurations can be provided. They require special Redundancy Kit. The Advantech’s LNA provides an industry leading MTBF of over 200,000 hours.
Features
- Input X-Band frequencies from 7.25 to 7.75 GHz
- GaAs/HEMT Technology
- Built-in Interstage Transmit Reject Filter
- Pressurizable W/G Input
- Power supply via RF connector or Power Connector
- Built-in alarm circuit
- Extreme operating temperature
- Weatherproof housing
- Three year warranty
- Over 200,000 Hours MTBF
Options
- Input Isolator
- Redundant system with automatic and manual switching
- Remote monitor and control panel
Accessories
- Input Isolator
- External Transmit Reject Filter
Overview
The Advantech’s Low Noise Amplifier (LNA) ALNA-X is a low noise, highly dynamic range amplifier suitable for use in satellite earth station receiver applications where ultra low noise and high reliability are critical. Advantech also provides LNAs in C, S Ku and Ka bands. The X-band LNA is available with Noise Temperature ranging from 60 K to 70 K. With weatherproof packaging, the LNA can meet the demands of the installations in severe environmental conditions. The 1:1 and 1:2 redundant system configurations can be provided. They require special Redundancy Kit. The Advantech’s LNA provides an industry leading MTBF of over 200,000 hours.
Features
- Input X-Band frequencies from 7.25 to 7.75 GHz
- GaAs/HEMT Technology
- Built-in Interstage Transmit Reject Filter
- Pressurizable W/G Input
- Power supply via RF connector or Power Connector
- Built-in alarm circuit
- Extreme operating temperature
- Weatherproof housing
- Three year warranty
- Over 200,000 Hours MTBF
Options
- Input Isolator
- Redundant system with automatic and manual switching
- Remote monitor and control panel
Accessories
- Input Isolator
- External Transmit Reject Filter
- Узнайте по тел.: +7 (495) 105 96 88
- Напишите нам письмо: info@micro-electronics.ru
- Узнайте по тел.: +7 (495) 105 96 88
- Напишите нам письмо: info@micro-electronics.ru
- Реестр СИ не требуется
- Реестр СИ не требуется
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Производитель | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Товар |
|
|
|
Модели и Опции |
Описание |
Цена | Заказать |
0
| Модели |
|
ALNA-X
|
Выходная частота 7,25 - 7,75 МГц
|
По запросу |
