Пробник поля 10 кГц - 6 ГГц (в соотв. IEC/EN 61000-4-3) 0,1 В/м - 10 кВ/м Frankonia EFS-LASER

EFS-LASER
Для увеличения картинки наведите мышкой
EFS-LASER
EFS-LASER
НаличиеПо запросу
По запросу
По запросу
По запросу
Измерители напряженности поля EFS-LASER Подробнее
Обзор
Свернуть Развернуть
Основные возможности и технические характеристики

The Frankonia EFS-LASER Electric Field Probe especially has been designed for field strength measurements / field homogeneity measurements during radiated immunity tests according to IEC/EN 61000-4-3. However, it is also excellent to measure the radiation pollution of the environment, for example at workplaces or flats.

The EFS-LASER is an isotropic miniature E-field sensor to ensure, that the E-field will not be influenced by the size of the sensor itself. It even does not need any metering unit (which could also influence the field-strength), because of its direct fibre-optic output, which does allow direct connection of the sensor to the USB-interface of the control PC or laptop. The measuring values may be displayed via the individual IEC 61000-4-3 control software or via a windows-software included in the delivery.

The EFS-Laser cover the frequency-range from 10 KHz – 6 GHz. The utilized linearization technology provides a dynamic range up to 100 dB. The EFS-Laser is a smart, fast, extremely accurate electric field probe, which provides linearization, temperature compensation, control and communication functions. Noise reduction and temperature compensation allow accurate measurments down to 0.1 V/m. The probe is laser-powered to allow continuous, galvanically isolated operation without recharging or battery replacement The power supply unit comes in a small handy box.

Features
  • Laser powered – no more empty batteries
  • Extreme small size
  • High resolution, high speed, low noise
  • Frequency range: 10 kHz to 6 GHz
  • Field strength measurements from 0.1 V/m up to 10 kV/m
  • Wide dynamic range
  • Continuous real-time data streaming
  • Temperature compensation



  • Свернуть Развернуть
    Основные возможности и технические характеристики

    The Frankonia EFS-LASER Electric Field Probe especially has been designed for field strength measurements / field homogeneity measurements during radiated immunity tests according to IEC/EN 61000-4-3. However, it is also excellent to measure the radiation pollution of the environment, for example at workplaces or flats.

    The EFS-LASER is an isotropic miniature E-field sensor to ensure, that the E-field will not be influenced by the size of the sensor itself. It even does not need any metering unit (which could also influence the field-strength), because of its direct fibre-optic output, which does allow direct connection of the sensor to the USB-interface of the control PC or laptop. The measuring values may be displayed via the individual IEC 61000-4-3 control software or via a windows-software included in the delivery.

    The EFS-Laser cover the frequency-range from 10 KHz – 6 GHz. The utilized linearization technology provides a dynamic range up to 100 dB. The EFS-Laser is a smart, fast, extremely accurate electric field probe, which provides linearization, temperature compensation, control and communication functions. Noise reduction and temperature compensation allow accurate measurments down to 0.1 V/m. The probe is laser-powered to allow continuous, galvanically isolated operation without recharging or battery replacement The power supply unit comes in a small handy box.

    Features
  • Laser powered – no more empty batteries
  • Extreme small size
  • High resolution, high speed, low noise
  • Frequency range: 10 kHz to 6 GHz
  • Field strength measurements from 0.1 V/m up to 10 kV/m
  • Wide dynamic range
  • Continuous real-time data streaming
  • Temperature compensation



  • Комплектацию Вы можете узнать:
    По тел.: +7 (495) 105 96 88 или
    Написать нам письмо: info@micro-electronics.ru
    Комплектацию Вы можете узнать:
    По тел.: +7 (495) 105 96 88 или
    Написать нам письмо: info@micro-electronics.ru
    Свернуть Развернуть
    Сведения о реестре СИ

    Номер в Госреестре

    Наименование СИ

    Обозначение типа СИ

    Изготовитель

    Срок свидетельства или заводской номер

    Не в реестре
    Свернуть Развернуть
    Сведения о реестре СИ

    Номер в Госреестре

    Наименование СИ

    Обозначение типа СИ

    Изготовитель

    Срок свидетельства или заводской номер

    Не в реестре
    Характеристики
    Загрузить технические характеристики

    Computer-Interface
    PC Interface USB 2.0
    Application Software included
    Burst Trigger Output Level 3.3 V CMOS
    Burst Trigger Output Connector BNC
    Laser – Wavelength 850 nm
    Laser – Output Power 750 mW
    Laser – Shutdown Time 1 ms
    Fiber Optic Connector FC / ST
    Fiber Optic Cable Length 15 m
    Max. Fiber Optic Cable Length 100 m (sold on request)
    Input Voltage (power supply included) 5V ± 5%
    Input Current < 2A
    Ambient Temperature 10 °C … 40 °C
    Dimensions (W x D x H) 483 x 43.5 (1HE) x 120mm
    Field Sensor
    Frequency range 10 kHz … 6GHz
    Analog Rise Time
    10 kHz … 100 MHz low Bandwidth 4 μs
    10 kHz … 100 MHz high Bandwidth 40 ns
    100 MHz … 6 GHz 25 ns
    Minimum Pulse Width
    Burst Mode 500 ns
    Streaming Mode 2 μs
    Resolution
    Sampling Rate < 0.01 dB
    Burst Mode 2 MSample/s
    Streaming Mode > 500 kSample/s
    Field Strength
    10 kHz … 100 MHz < 1 V/m … > 10 kV/m
    100 MHz … 6 GHz < 0.1 V/m … > 700 V/m
    Damage Level
    10 kHz … 100 MHz 40 kV/m
    100 MHz … 6 GHz 10 kV/m
    Dynamic Range
    10 kHz … 100 MHz 80 dB … 100 dB
    100 MHz … 6 GHz 70 dB … 80 dB
    Isotropy, 900 MHZ < 1dB
    Amplitude Accuracy
    10 kHz … 10 MHz (1.5 V/m to 30 V/m) 1.3 dB
    > 10 MHz … 1 GHz (1 V/m to 80 V/m) 1.5 dB
    > 1 GHz … 8 GHz (3 V/m to 100 V/m) 1.0 dB
    Linearity Error < 0.1 dB
    Temperature Stability 0.1 dB
    Ambient Temperature 10 °C … 40°C
    Dimensions (W x D x H) 67 x 67 x 124 mm
    Модели и опции
    Товар
    Модели и Опции
    Описание
    Цена Заказать
    Модели
    EFS-LASER
    Пробник поля 10 кГц - 6 ГГц (в соотв. IEC/EN 61000-4-3) 0,1 В/м - 10 кВ/м
    По запросу
