Измерительный приемник на предварительное/полное соответствия 10 Гц – 6 ГГц

9010/XXP
Для увеличения картинки наведите мышкой
9010/XXP9010/XXP9010/XXP
9010/XXP9010/XXP9010/XXP
НаличиеПо запросу
По запросу
По запросу
По запросу
Приемники измерительные ЭМП 9010/XXP Подробнее
Обзор
Свернуть Развернуть
Основные возможности и технические характеристики

Narda-PMM has developed new EMI / EMC receivers based on an innovative concept and a revolutionary approach to meet the needs of small and medium-sized laboratories that do not find it convenient to invest in a receiver conforming to the CISPR 16-1-1 also for radiated measurements.

They are a perfect mix of full and Pre-Compliance to meet, in a perfect way, the requirements of practical tests, not excluding the possibility of future upgrades to 100% Full-Compliant to CISPR 16-1-1 up to 3, 6 or 18 GHz the simple addition of an external unit, 9030, 9060 or 9180, connected via fiber optic cable.

The 9010 / xxP series receivers, are full compliance in accordance with the CISPR 16-1-1 in the band A and B and pre compliance in the next

Receivers 9010/xxp are available in the following versions:

  • 9010/03P, 10 Hz – 300 MHz
  • 9010/30P, 10 Hz – 3 GHz
  • 9010/60P, 10 Hz – 6 GHz
  • Свернуть Развернуть
    Основные возможности и технические характеристики

    Narda-PMM has developed new EMI / EMC receivers based on an innovative concept and a revolutionary approach to meet the needs of small and medium-sized laboratories that do not find it convenient to invest in a receiver conforming to the CISPR 16-1-1 also for radiated measurements.

    They are a perfect mix of full and Pre-Compliance to meet, in a perfect way, the requirements of practical tests, not excluding the possibility of future upgrades to 100% Full-Compliant to CISPR 16-1-1 up to 3, 6 or 18 GHz the simple addition of an external unit, 9030, 9060 or 9180, connected via fiber optic cable.

    The 9010 / xxP series receivers, are full compliance in accordance with the CISPR 16-1-1 in the band A and B and pre compliance in the next

    Receivers 9010/xxp are available in the following versions:

  • 9010/03P, 10 Hz – 300 MHz
  • 9010/30P, 10 Hz – 3 GHz
  • 9010/60P, 10 Hz – 6 GHz
  • RS232 cable
  • USB-RS232 serial converter
  • USB cable
  • BNC-BNC cable,
  • N-m to BNC-f adapter
  • AC/DC power adapter
  • PES Emission Suite software
  • Soft
  • Carrying case
  • User’s manual
  • Standard calibration certificate

  • RS232 cable
  • USB-RS232 serial converter
  • USB cable
  • BNC-BNC cable,
  • N-m to BNC-f adapter
  • AC/DC power adapter
  • PES Emission Suite software
  • Soft
  • Carrying case
  • User’s manual
  • Standard calibration certificate

  • Свернуть Развернуть
    Сведения о реестре СИ

    Номер в Госреестре

    Наименование СИ

    Обозначение типа СИ

    Изготовитель

    Срок свидетельства или заводской номер

    Не в реестре
    Свернуть Развернуть
    Сведения о реестре СИ

    Номер в Госреестре

    Наименование СИ

    Обозначение типа СИ

    Изготовитель

    Срок свидетельства или заводской номер

    Не в реестре
    Характеристики
    Загрузить технические характеристики

    SPECIFICATIONS Input 10 Hz to 30 MHz Input 30 MHz to 300 MHz (9010/03P) Input 30 MHz to 3 GHz (9010/30P) Input 30 MHz to 6 GHz (9010/60P)
    Frequency range
    Resolution, Freq. accuracy
    10 Hz to 30 MHz  0,1 Hz, < 1 ppm 30 MHz to 300 MHz  100 Hz, < 2 ppm 30 MHz to 3 GHz  100 Hz, < 2 ppm 30 MHz to 6 GHz  100 Hz, < 2 ppm
    RF Input Zin 50 Ω, BNC fem. Zin 50 Ω, N fem. Zin 50 Ω, N fem. Zin 50 Ω, N fem.
    VSWR 10 dB RF att. < 1,2 < 1,2 < 1,2, < 2,0 over 1 GHz < 1,2, < 2,0 over 1 GHz
    0 dB RF att. < 2,0 < 1,2 < 1,2, < 2,0 over 1 GHz < 2,0, < 3,0 over 1 GHz
    Attenuator 0 dB to 35 dB (5dB steps) 0 dB to 50 dB (2dB steps) 0 dB to 50 dB (2 dB steps) 0 dB to 55 dB (5 dB steps)
    Pulse limiter Built in (selectable) n.a. n.a. n.a.
    Preamplifier gain 20 dB (after preselector, selectable) n.a. n.a. n.a.
    Max input level
    Sinewave AC voltage
    Pulse spectral density
    (without equipment damage)
    137 dBμV (1 W)
    97 dBμV∕MHz
    Preselector < 9 kHz n.a. n.a. n.a.
    One lowpass filter 9 to 150 kHz, 150 to 500 kHz,
    Six bandpass filters 500 kHz to 3 MHz, 3 to 10 MHz,  10 to 20 MHz, 20 to 30 MHz
    IF bandwidth
    Standard 3/6 dB (3 dB BW) 3, 10, 30, 100, 300 kHz (6 dB BW) 3, 10, 30, 100, 300 kHz, 1 MHz (6 dB BW) 3, 10, 30, 100, 300 kHz, 1 MHz (6 dB BW) 3, 10, 30, 100, 300 kHz, 1 M
    CISPR-16-1-1 200 Hz; 9 kHz 120 kHz 120 kHz 120 kHz
    MIL-STD-461 (option) 10, 100 Hz, 1, 10 kHz 100 kHz, 1 MHz 100 kHz, 1 MHz 100 kHz, 1 MHz
    Noise level (Preamplifier ON)
    9 to 150 kHz < - 8 dBμV (QP)
    (200 Hz RBW) < - 15 dBμV (AV)
    30 MHz to 300 MHz < 8 dBμV (QP)
    (120 kHz RBW) < 4 dBμV (AV)
    30 MHz to 3 GHz < 8 dBμV (QP)
    (120 kHz RBW) < 4 dBμV (AV)
    30 MHz to 300 MHz < 10 dBμV (QP)
    (120 kHz RBW) < 7 dBμV (AV)
    0,15 to 30 MHz < - 4 dBμV (QP)
    (9 kHz RBW) < - 10 dBμV (AV)
    300 MHz to 3 GHz < 13 dBμV (QP)
    (120 kHz RBW) < 7 dBμV (AV)
    3 GHz to 6 GHz < 15 dBμV (QP)
    (120 kHz RBW) < 10 dBμV (AV)
    Measuring detectors Peak, Quasi-Peak, Average, RMS, RMS-Average, CISPR-Average, APD and Smart Detector function
    Level measuring time  Peak, Quasi-Peak, AVG, RMS (simultaneous detectors) 1 ms to 30 s. (CISPR 16-1-1 default)
    Display units dBm, dBμV (as stand-alone);  dBm, dBμV, dBμV∕m, dBmA, dBmA/m, dBpW (through 9010 SW Utility on PC)
    Spurious response < 0 dBuV, < 10dBuV over 150 kHz < 15 dBμV < 15 dBμV < 10 dBμV, < 15 dBμV over 2 GHz
    Measurement accuracy
    S/N > 20 dB
    10 Hz to 9 kHz ± 1,0 dB typical
    9 kHz to 30 MHz ± 1,0 dB
    ± 1 dB 30 MHz to 1 GHz ± 1,0 dB
    1 GHz to 3 GHz ± 1,5 dB
    30 MHz to 1 GHz ± 1,0 dB
    1 GHz to 3 GHz ± 1,5 dB
    3 GHz to 6 GHz ± 2,0 dB
    Demodulation Built-in AM demodulator (headphone jack)
    RF output (tracking generator) Zout 50 Ω, BNC fem.
    Frequency range 10 Hz to 50 MHz
    Level 60 dBμV to 90 dBμV (0,1 dB steps)
    Level accuracy ± 0,5 dB (10 Hz to 30 MHz)
    I/O Interface USB 2.0 (rear), USB 2.0 (front; only for future implementation), RS-232, high-speed optical link
    (2 channels; 2nd channel for future implementation), user port (for LISN connection, etc.),
    Bluetooth through optional adapter, IEEE-488 (GPIB) optional
    Operating temperature 0 °C to 40 °C
    Power supply 10 - 15 Volt DC, 2,5 A; optional Li-ion interchangeable battery (8h use, typical)
    Dimensions (W x H x D) 235 x 105 x 335 mm
    Weight 4,1 kg
    Модели и опции
    Товар
    Модели и Опции
    Описание
    Цена Заказать
    Модели
    9010/03P
    Измерительный приемник на предварительное/полное соответствия 10 Гц – 300 МГц
    По запросу
    - шт +
    9010/30P
    Full/Pre compliance receivers 10 Гц – 3 ГГц
    По запросу
    - шт +
    9010/60P
    Full/Pre compliance receivers 10 Гц – 6 ГГц
    По запросу
    - шт +
